OB module: ad-hoc meeting

Monday 14 Jul 2025, 14:00 → 15:30 Europe/London

Marcello Borri (staff@stfc.ac.uk), James Julian Glover (University of Birmingham (UK))

Please see Marcello's email for Zoom link.

14:00 → 14:15 University of Birmingham

Speakers: Che Sum Tse (University of Birmingham UK), James Julian Glover (University of Birmingham (UK))

-Planning to practive handling of dummy LAS: dummy LAS removal from transport gel paks;

-Are there any LAS5 RSU to practive module assembly? Yes, 8 units of 5RSU-LAS available to prototype 5 modules.

14:15 → 14:30 Brunel University

Speaker: Liliana Teodorescu (Brunel University London)

14:30 → 14:45 Daresbury Laboratory

Speakers: Marcello Borri (staff@stfc.ac.uk), Matthew Buckland (staff@stfc.ac.uk), Ken Davies (UKRI STFC Daresbury)




-Recevied from LTU the files containing the alignment holes. They can be shared with Oxford to complete the design of the carrier plates for the M-FPC and the B-FPC .

-Progress on the design of the tooling for the low readiness prototypes.

14:45 → 15:00 University of Liverpool

Speaker: Jian Liu (University of Liverpool)

Update_from_Liverpool_20250714.pdf

-delamination of FPCs observed when cleaning with safewash; (LTU suggested to clean wit acetone)

-the wirebond tests presented in the slides have tails of 250um;

-according to theory the diffuser supporting the FPC dissipates ultrasonic energy; supporting the FPC directly on a solid substrate reduces dissipation of ultrasonic energy and improves wirebonding quality; [This is not obvious from this results]

15:00 → 15:10 Other remarks

20250716-epicSvtPfcInterconnectionV0-rep-2021a10.pdf

dl559776a-layout.dxf

Info for K.Foster to progress desing of carrier plates required to interconnectr and test OB-FPC-L4-Protype1
